Dimensions: 214x86mm for PCB License.RouterBOARD 2011UiAS-2HnD has most features and interfaces from all our Wireless routers. CPU Nominal Frequency: 600MHz. 10/100/1000 Ethernet Ports: 5. Fast Path What are Fast Path Supporting Devices CCR, CRS, RB7xx, RB9xx, hEX, hAP, wAP,cAP, mAP, SXT, Metal, Groove, DynaDish, OmniTIK series - all ports RB1100 series ether1-11 (RB 1100x4 ALL port) RB6xx series and RB800 - ether1,2 RB1000, RB3011, RB2011 - all ports T&252 m Wireless Interfaceleri (6.37) All products in MicroTik or Interfaceler may not support Fast Path.10/100 Ethernet Ports: 5.
After the reboot, your router will be running the latest RouterOS version.Please follow these quick steps to set up your device:RB2011. Upgrade button in QuickSet: Upgrade button in the Packages menu: After clicking the Upgrade button, Changelog is shown: By clicking 'Download & Upgrade', downloads will start, and router will reboot. ConnectingManual upgrade is needed in this case. Also, it features powerful (up to 1W!) dual chain 2.4Ghz 802.11bgn wireless, RJ45 serial port, full-size USB port, and RouterOS L5 license.
Plug the included Switching Power Supply, if you are not using PoE, to start up the device. Connect your other local computers to the any of other Ethernet ports. Connect your internet provider Ethernet cable to the ETH1 port.
Rb2011 Password On The
Direct-input power jack (5.5 mm outside and 2 mm inside diameter, female, pin positive plug) accepts 8-30 V DC (overvoltage protection starts at 30 V). Choose your country, to apply country regulation settings, and set up your password on the screen that loads.The device accepts powering from either the power jack or from the LAN1 Ethernet port: We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best performance and stability. Once connected to the wireless network, open in your web browser to start configuration, since there is no password by default, you will be logged in automatically. Open network connections on your PC, mobile phone, or other device and search for MikroTik wireless network and connect to it.
Connect the Ethernet cable from the device to the POE port of the POE adapter. Connecting to a POE Adapter: The board does not work with IEEE802.3af compliant 48 V power injectors.Maximum power consumption 11 W.
MountingThe device is designed to be used indoors and placed on a flat surface with all needed cables connecting to the front of the unit. The PoE on Ether10 outputs approximately 2 V below input voltage and supports up to 0.58 A (So provided 24 V PSU will provide 22 V at 0.58 A output to the Ether10 PoE port). Connect the power cord to the adapter, and then plug the power cord into a power outlet.The device supports PoE out from Ethernet 10 port, you can power Mikrotik devices which supports powering through Ethernet.
Operation of this equipment in the residential environment could cause radio interference. Warning! This equipment should be installed and operated with a minimum distance of 20 cm between the device and your body. We recommend using Cat5/6 shielded cables. When mounting on the wall, please ensure that cable feed is pointing downwards. Grounding screw is located on the backside of the device case, please connect it accordingly to efficient ground. Screws with size 4x25 mm fit nicely, depending on your wall structure you can use dowels 6x30 mm and 6 mm drill bit if needed.
In case IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC address of the device from the LAN side (all access is blocked from the Internet port by default). We suggest starting here to get yourself accustomed to the possibilities. RouterOS includes many configuration options in addition to what is described in this document. For wireless models, please make sure you have selected the country where the device will be used, to conform with local regulations.
SFP port for SFP module (module not included, works only with Gigabit modules). Power out supports auto-detect to protect devices. Ether10 supports 500 mA output power, ~2 V below the input voltage. Five 10/100 (Fast) Ethernet ports (Auto MDI/X). Five 10/100/1000 (Gigabit) Ethernet ports (Auto MDI/X).
Or Keep holding the button for 5 more seconds until LED turns off, then release it to make the RouterBOARD look for Netinstall servers connected to its first Ethernet port (total 15 seconds).Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device. The device will now look for a CAPsMAN server (total 10 seconds). Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (total 5 seconds).
MikroTik mobile appUse the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for your MikroTik home access point. This is a class A device, operating it near residential radio equipment could cause radio interference. This equipment is to be serviced by trained personnel only. Safety NoticeElectric shock hazard. Other operating systems have not been tested.
Datasheet for any device is available on the official manufacturer website. For Outdoor Usage: End-user requires approval/license from the NTRA. In case WLAN devices work with different ranges than the above regulations, then a customized firmware version from the manufacturer/supplier is required to be applied to the end-user equipment and also prevent the end-user from reconfiguration.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: However, there is no guarantee that interference will not occur in a particular installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. These limits are designed to provide reasonable protection against harmful interference in a residential installation. All MikroTik radio devices must be professionally installed.Federal Communication Commission Interference StatementFCC ID: TV7RB2011-2HND This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Part 15 of the FCC Rules. Consult the dealer or an experienced radio/TV technician for help.FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Increase the separation between the equipment and receiver.
